About this product

The Walksnail Avatar HD Nano Camera / Mini 1S VTX Kit features a nano digital camera, antenna, and mini VTX that works with HD Goggles such as the Walksnail Avatar and Fat Shark HD Dominator. This mini HD VTX combo has lower latency than the competitor at an average of 22ms, with an onboard DVR, 5.8GHz frequency, 8Gb internal storage, and a switchable aspect ratio.

Features

Lower latency than the competitor at an average of 22ms
6.8g Lightweight Mini VTX great for the 75x Quad
Walksnail Avatar Mini 1S VTX Module
Walksnail Avatar Nano Camera
Built-in 8Gb Internal Storage
1080p Screen Resolution
Switchable Aspect Ratio
Walksnail IPEX Antenna
5.8GHz Frequency
Onboard DVR
Canvas Mode
170° FOV
3.1V-5V

Specifications

AVATAR HD NANO CAMERA

Resolution: 1080p 60FPS / 720P 120FPS / 720P 60FPS
Aspect Ration: 16/9 and 4/3 Switchable
Minimum Illumination: 0.001Lux
Shutter Style: Rolling Shutter
Dimensions: 14x14x17mm
Cable Length: 90mm
Image Sensor: 1/27"
Field Of View: 170°
Aperture: F 2.0
Lens: 2.1mm
Weight: 3.5g

AVATAR MINI 1S VTX MODULE

Transition Power: FCC<25.5dBm / CE <14dBm / SRRC <20dBm / MIC <25dB
I/O Interface: JST1.0 x 6 (Power In) to JST1.0 x 4 (USB)
Operational Frequency: 5.725-5.850GHz
Operating Temperature: -20° to 40°c
Supported FC Firmware: Betaflight
Video Resolution: 1080p / 720p
Dimensions: 33x33x6.5mm
Antenna Connector: IPEX
Bitrate: 25mbps/50mbps
Mounting: 25.5x25.5mm
Latency: 22ms Average
Internal Storage: 8GB
Input Voltage: 3.1-5V
OSD: Canvas Mode
Weight: 6.8g
Channels: 8

WALKSNAIL AVATAR VTX ANTENNA

Radiation Efficiency: >= 98%
Bandwidth: 5.6-5.9GHz
Gain: 2dBi Average
Polarization: LHCP
Connector: IPEX
Length: 90mm
VSWR: <=1.4
Weight: 1.5g

Includes

1x Walksnail Avatar HD Nano Camera w/ Avatar Mini 1S VTX
1x Walksnail Avatar IPEX Antenna
1x 6-Pin Power Cable
2x M2 4mm Screws
1x 4-Pin USB Cable
