Specifications:
- Total Dimensions: 136*190mm (body dimension)
- Geometry: Squashed-X or DC (DeadCat) frame available
- Bottom to top distance: 28mm
- Arm Thickness: 6mm
- Bottom plate thickness: 3mm
- Top plate thickness: 3mm
- Upper(middle) plate thickness: 3mm
- XING2 2207 motors (4S/6S)
- Nazgul F5 propellers
- Weight: 412g (without battery and GoPro mount)
-Caddx DJI Vista
FC // SucceX-D Mini F7
- MCU: 216MHz STM32F722
- Gyro：2x ICM20689
- Blackbox：32MB
- Betaflight OSD: YES
- BEC: 5V 2.5A / 9V 2.5A
- Current sensor scale: 100
- Inverter for SBUS input (UART2-RX)
- Smart audio & Tramp VTX protocol supported
- Beeper pad: Yes
- RSSI input pad: No
- UARTs：5
- Motor outputs: 4
- 8 pin 4in1 ESC port (GND, VBAT, M1, M2, M3, M4, CUR, R5)
- 6 pin DJI Air Unit port (R1, GND, R2, T2, GND, 9V)
- BLHeli32 Telemetry：Yes
- Input voltage：recommended 2-6S, MAX 6S
- Firmware target: IFLIGHT_F722_TWING
- Mounting pattern: 20*20mm φ4
- Dimensions: 29*29mm
- USB Type-C
ESC // SucceX Mini 55A
- Dimension: 31*29.5mm
- Mounting Holes: 20*20mm/Φ4mm
- Weight: 10.8g
- Supports 2-6S Lipo input
- MCU： G071
- Constant: 55 Amps
- Burst: 60 Amps
- Current sensor: Yes
- BEC: No
- Current rate: 100
- Supports DShot DShot150/300/600/MultiShot/ OneShot etc.
- Firmware: BLHeli 32
- Target: iFlight-G071-4IN1
Package included：
- 1 x Nazgul Evoque F5 (Deadcat)
- 4 x Nazgul F5 Prop
- 2 sets of Battery Pads
- 4 x Battery straps
- 1 x Screws bag
