OCP 5.8Ghz
OCP 5.8Ghz
Regular price
153,00kr SEK
Regular price
Sale price
153,00kr SEK
Unit price
/
per
In stock
The OCP 5.8 is an everyday omni antenna. Proven design, great signal, durable and look amazing. Select polarization, connector and cable please
Features
- Durable poly-carbonate, Injection Molded, ultra-sonically welded Housing
- Clear indication of polarization direction
- Excellent axial ratio and efficiency
- Flexible coax cable option that deflect impacts
- Knurled True-SMA for easy tightening
- Quality MMCX/90 that snap on DJI fpv securely
Specs:
- Gain: 1.6dBic
- Polarization: RHCP or LHCP
- Cross-Polar Rejection: -10 to -20dB, (3.2%)
- Bandwidth: 5.6GHz-6.0GHz
- Radiation Efficiency: 98%
- SWR: <=1.2:1
- Weight: Vary with connector/cable option
- Dimensions(head): 16.5mm dia. x 10.7mm height.
- Length: Vary with cable option
- Cable: TrueRC RG316S/RG402/RG178 coax
- Connector: Reinforced True-SMA/90 male, U.FL, MMCX/90
